Edge-Core DCS203 [AS7326-56X]
Описание устройства
The Edgecore DCS208 switch meets the high-performance, availability, and network-scaling requirements of
enterprise and cloud data centers. The DCS208 provides full line-rate switching at Layer 2 or Layer 3 across 48 x
10GbE ports and 6 x 40GbE uplinks. The switch can be deployed either as a top-of-rack switch, or as part of a
10GbE or 40GbE distributed spine, forming a non-blocking folded-Clos data center fabric. The switch is rack
mountable in either a standard 19 inch rack, or with the Open Rack Switch Adapter in the 21 inch Open Rack.
The DCS208 hardware provides the high availability features required for data center operation, including
redundant, hot-swappable AC or -48 VDC PSUs or 12 VDC power input; 4+1 redundant fan modules; and
front-to-back or back-to-front airflow options. The DCS208 is an ideal top-of-rack switch for virtualized data
centers, with its support of VXLAN and NVGRE tunneling functions in hardware. This open network switch is loaded
with the Open Network Install Environment (ONIE), which supports the installation of compatible Network
Operating System soſtware, including the open source options, plus commercial NOS offerings.
48 x 25G SFP28 + 8 x 100G QSFP28 with Trident 3
■ Deploy as TOR switch supporting 10 or 25 GbE to servers, with 40 GbE, or 100 GbE uplinks.
■ 48 x SFP28 + 8 x QSFP28 switch ports, each QSFP28 supporting 1 x 100 GbE or 1 x 40 GbE, or via breakout
cables, 4 x 25 GbE, or 4 x 10 GbE.
■ Layer 2 or Layer 3 forwarding of 2 Tbps.
■ Supports hot/cold aisles with front-to-back or back-to-front airflow SKUs.
■ All ports on front; PSUs and fans accessible from rear.
■ Hot-swappable, load-sharing, redundant AC or -48V DC PSUs.
■ 5+1 redundant, hot-swappable fan modules.
■ Energy efficient.
■ Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of
compatible open source and commerical NOS offerings.
48 x 25G SFP28 + 8 x 100G QSFP28 with Trident 3
■ Deploy as TOR switch supporting 10 or 25 GbE to servers, with 40 GbE, or 100 GbE uplinks.
■ 48 x SFP28 + 8 x QSFP28 switch ports, each QSFP28 supporting 1 x 100 GbE or 1 x 40 GbE, or via breakout
cables, 4 x 25 GbE, or 4 x 10 GbE.
■ Layer 2 or Layer 3 forwarding of 2 Tbps.
■ Supports hot/cold aisles with front-to-back or back-to-front airflow SKUs.
■ All ports on front; PSUs and fans accessible from rear.
■ Hot-swappable, load-sharing, redundant AC or -48V DC PSUs.
■ 5+1 redundant, hot-swappable fan modules.
■ Energy efficient.
■ Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of
compatible open source and commerical NOS offerings.
